Raspberry pi -

A Raspberry Pi is a small computer that can run a full operating system (usually Linux). It has more power and features than a microcontroller, like USB ports, HDMI output, Wi-Fi, and the ability to run complex software.

There are various types of  Raspberry pi model

1. Raspberry Pi 4 Model B
2. Raspberry Pi 3 Model B+
3. Raspberry Pi 3 Model B
4. Raspberry Pi Zero 2 W
5. Raspberry Pi Zero W
6. Raspberry Pi 400
7. Raspberry Pi Pico

How to install Raspberry pi 4

•  Go to google and paste this link https://www.raspberrypi.com/softwar
• Clink on Download


• install this imager
•



• insert SD card in card reader and connect to computer and click on choose storage.
•  After process remove SD card and put in Raspberry pi
• And connect Raspberry pi to monitor/computer/laptop by HDMI cable and c-type cable, Now you can use Raspberry pi.

Light blink code for pi

from gpiozero import LED

from time import sleep

led = LED(17)  # Connect LED to GPIO 17

while True:

    led.on()

    sleep(1)

    led.off()

    sleep(1)

//gpiozero is a Python library that makes it very easy to use the GPIO (General Purpose Input Output) pins on a Raspberry Pi.

Traffic light project:-

import RPi.GPIO as GPIO

import time

# Set GPIO mode

GPIO.setmode(GPIO.BCM) #Broadcom SoC (chip) numbering

# Assign GPIO pins

RED = 17

YELLOW = 27

GREEN = 22

# Set up pins as output

GPIO.setup(RED, GPIO.OUT)

GPIO.setup(YELLOW, GPIO.OUT)

GPIO.setup(GREEN, GPIO.OUT)

def traffic_light_cycle():

    while True:

        # Green light on

        GPIO.output(GREEN, True)

        GPIO.output(YELLOW, False)

        GPIO.output(RED, False)

        time.sleep(5)



        # Yellow light on

        GPIO.output(GREEN, False)

        GPIO.output(YELLOW, True)

        time.sleep(2)



        # Red light on

        GPIO.output(YELLOW, False)

        GPIO.output(RED, True)

        time.sleep(5)

try:

    traffic_light_cycle()

except KeyboardInterrupt:

    print("Traffic light simulation stopped by user.")

finally:

    GPIO.cleanup()

IR sensor connect to Raspberry pi

   import RPi.GPIO as GPIO

import time

# Pin definitions

IR_SENSOR = 17  # GPIO pin number

# Setup

GPIO.setmode(GPIO.BCM)

GPIO.setup(IR_SENSOR, GPIO.IN)

print("IR Sensor Test (press Ctrl+C to exit)") #optional

try:

    while True:

        if GPIO.input(IR_SENSOR) == 0:

            print("Object detected!")

        else:

            print("No object.")

        time.sleep(0.5)

except KeyboardInterrupt:

    print("Program stopped.")

finally:

    GPIO.cleanup()



Motor connect to Raspberry pi :-

import RPi.GPIO as GPIO

import time

# Pin definitions

IN1 = 17

IN2 = 18

IN3 = 22

IN4 = 23

# Setup

GPIO.setmode(GPIO.BCM)

GPIO.setup(IN1, GPIO.OUT)

GPIO.setup(IN2, GPIO.OUT)

GPIO.setup(IN3, GPIO.OUT)

GPIO.setup(IN4, GPIO.OUT)

def stop():

    GPIO.output(IN1, False)

    GPIO.output(IN2, False)

    GPIO.output(IN3, False)

    GPIO.output(IN4, False)

def forward():

    GPIO.output(IN1, True)

    GPIO.output(IN2, False)

    GPIO.output(IN3, True)

    GPIO.output(IN4, False)

def backward():

    GPIO.output(IN1, False)

    GPIO.output(IN2, True)

    GPIO.output(IN3, False)

    GPIO.output(IN4, True)

def left():

    GPIO.output(IN1, False)

    GPIO.output(IN2, True)

    GPIO.output(IN3, True)

    GPIO.output(IN4, False)

def right():

    GPIO.output(IN1, True)

    GPIO.output(IN2, False)

    GPIO.output(IN3, False)

    GPIO.output(IN4, True)

try:

    print("Moving Forward")

    forward()

    time.sleep(3)

    stop()

    time.sleep(60)

    print("Moving Backward")

    backward()

    time.sleep(3)

    stop()

    time.sleep(60)

    print("Turning Left")

    left()

    time.sleep(1.5)

    stop()

    time.sleep(60)

    print("Turning Right")

    right()

    time.sleep(1.5)

    stop()

    time.sleep(60)

except KeyboardInterrupt:

    print("Stopped by user.")

finally:

    stop()

    GPIO.cleanup()

Ultrasonc Code in pi

import RPi.GPIO as GPIO

import time

# Pin Definitions

TRIG = 23

ECHO = 24

GPIO.setmode(GPIO.BCM)

GPIO.setup(TRIG, GPIO.OUT)

GPIO.setup(ECHO, GPIO.IN)

def measure_distance():

    # Send 10us pulse to trigger

    GPIO.output(TRIG, True)

    time.sleep(0.00001)

    GPIO.output(TRIG, False)

    start_time = time.time()

    stop_time = time.time()

    # Wait for Echo pin to go HIGH

    while GPIO.input(ECHO) == 0:

        start_time = time.time()

    # Wait for Echo pin to go LOW

    while GPIO.input(ECHO) == 1:

        stop_time = time.time()

    # Calculate pulse duration

    elapsed = stop_time - start_time

    # Calculate distance (speed of sound = 34300 cm/s)

    distance = (elapsed * 34300) / 2

    return distance

try:

    while True:

        dist = measure_distance()

        print(f"Distance: {dist:.2f} cm")

        time.sleep(1)

except KeyboardInterrupt:

    print("Measurement stopped by user.")

finally:

    GPIO.cleanup()

Servo connect to pi

import RPi.GPIO as GPIO

import time

servo_pin = 18

GPIO.setmode(GPIO.BCM)

GPIO.setup(servo_pin, GPIO.OUT)

pwm = GPIO.PWM(servo_pin, 50)  # 50Hz frequency

pwm.start(0)

def set_angle(angle):

    duty = 2 + (angle / 18)  # Convert angle to duty cycle

    pwm.ChangeDutyCycle(duty)

    time.sleep(0.5)

    pwm.ChangeDutyCycle(0)  # Stop sending signal to avoid jitter

try:

    set_angle(45)  # Move servo to 45 degrees

    time.sleep(2)  # Wait for 2 seconds to hold position

finally:

    pwm.stop()

    GPIO.cleanup()
